ATOMIC Linear RC Cap Pack /ESC Pack / 8-16S / 4,500uF Minimum / 80V / USA

Built for high-voltage large-scale RC systems, the 8–16S Linear Cap Pack delivers stable, low-noise power to your ESC in a compact, rugged design. Engineered for demanding applications, this pack helps reduce electrical stress and improve system reliability in extreme setups.

High-voltage LiPo systems combined with long battery leads can introduce voltage ripple, electrical noise, and switching-related transients at the ESC. These conditions increase stress on internal components and can impact long-term performance.

This cap pack is designed to:

• Reduce voltage ripple under heavy load

• Stabilize power delivery during rapid throttle changes

• Minimize electrical noise and transient spikes

• Improve ESC reliability in high-voltage applications

• High-Voltage Electrolytic Bank
  4,500µF minimum designed for 8–16S systems

• Ultra-Low ESR Design
  Optimized for high current delivery and reduced losses

• Linear Compact Layout
  Ideal for inline mounting in larger chassis

• Water-Resistant Construction
  Built for real-world RC environments

• Genuine Nichicon capacitors

• High-temperature rated components

• 10 AWG silicone wire for high current applications

• Fully assembled and tested

• Capacitance value recorded on each unit

• Voltage Range: 8S – 16S LiPo

• Max Voltage: 80 VDC

• Capacitance: 4,500µF minimum

• Wire Length: 5.90 in (150 mm)

• Dimensions: 93mm × 18mm × 40mm

• Install as close to the ESC as possible

• Recommended for high-voltage systems and longer battery leads

• Helps protect ESC from ripple and voltage spikes in demanding applications

Designed and assembled with attention to detail and performance.

• 1/5 and large-scale RC

• 8S–16S LiPo systems

• High-voltage, high-power setups

• Users looking to improve electrical stability and protect their ESC

If you’re running high-voltage power systems and want a compact solution to clean up your electrical behavior and reduce stress on your electronics, this pack delivers reliable performance where it matters most.
